1, Cold glue stick paper machine
Main technical parameter:
1, Working size: 1220 * 2440(mm)
2, Working speed: 2-16m/min
3, Total power: 18kw
4, Working speed: 2-16m/min
5, Overall size: 12800 * 2200 * 1700(mm)
6, Weight: 2800KG
2, PUR stick paper machine
Main technical parameter:
1,Frame main machine: Whole steel plate welding
2,Frame auxiliary machine : Square tub welding + Aluminum
3,Working width: 600-1300mm(Optional width: 1220mm,1300mm,1800mm,2100mm)
4,Working length: 800-3000mm
5,Working thickness:1-45mm
6,Working speed: 1-20m/min
7,Size gumming roller: 240 * 1300(mm)
8,Heating gumming roller: Heating conduction oil
9,Size scraping roller: 240 * 1300(mm)
10,Size pressing roller: 240 * 1300(mm)
11,Cold press roller: Heating steel roller
12,Hot press roller: Heating steel roller
13,Dust-control motor: 0.75kw
14,Lifting motor: 0.75kw * 2(With reducer)
15,Gumming motor: 1.1kw(With reducer)
16,Pressing motor: 0.75kw * 4(With reducer)
17,Pre-heating power: 15kw
18,Oven heating power: 15kw
19,Lifting method: Automatic control
20,Friving method: Frequency control
21,Voltage condition: 380V/220V/44V etc(Customized)
22,Overall size(L*W*H): 20*3.2*0.9(m)
